Features :
» Processing and repairing the rotation hole, reaming, pin-hole, installation and remaining
hole of structure member for kinds of machine.
» The spindle adopts 220V motor with the feature of higher torque at lower speed.
» There is no vibration for the axial movement and cutting process to ensure stable
cutting.
» Processing and repairing concentric interval hole of excavator and crane.
» Processing porous one-time, ensuring porous in alignment.
SPECIFICATIONS :
MODEL |
SIZE |
Min. boring dia. |
45mm |
| Max. boring dia. | 200mm |
| Boring bar | 40 x 1500mm |
| Spindle speed | 0 to 80rpm/min |
| Max. stroke | 300mm (Standard) |
| Max. cutting depth | 2mm (single side) |
| Motor power | 1.5Kw, DC motor |
| Roughness of boring | Ra3.2 |
| Roundness tolerance | ≤0.02mm |
| Net. Weight | 100kg |
