Pipe Beveling Machine BBM-8000 Series

 Home / Products / Pipe Beveling Machine

BBM-8000 Series


Pipe

Send enquiry for Boiler Tube Expander


The BBM-8000 is a heavy duty pipe beveling machine, pipe facing machine, with wide range tube ID. This beveling machine is design to bevel face and weld age preparation for heavy wall thickness tubes. Modular and ergonomic design with high torque to suit in toughest heavy duty working condition.



Model

-

Electric

Pneumatic

Locking Range

MM

49 - 203

49 - 203

Idal Speed

RPM

35

50

Torque

NM

265

252

Feeding Stroke

MM

40

40

Pneumatic Power

HP

-

1.85

Air Consumption

CFM

-

62 - 65

Air Pressure

BAR (PSI)

-

6 (90)

Air Hose Connection

BSP

-

3/4"

Electric Power

WATT

1100

-

Voltage

VOLT

220/110

-

Frequency

Hz

50

-

Max Noise Level

dB

75

75

Unit Weight

KG

26.0

24.5
