Line Boring And Welding Machine - Unicorn 50


Electric

Send enquiry for Boiler Tube ExpanderTube Cleaner


FEATURES:

» The powerful automatic protection function makes the SILBWM-50 have a longer service life, and it is easier to be maintenance-free.
» Boring and repair welding-boring and automatic inner circle repair welding only needs one revolution to complete the system switching, making the operation more convenient.
» Boring and repair welding-boring and automatic inner circle repair welding only needs one revolution to complete the system switching, making the operation more convenient.
» Automatic inner circle repair welding can be used for jump welding, sector welding, full circle welding, slot welding and other requirements.





SPECIFICATIONS :

Sr. No.

Model

SILBWM-50 line boring and welding machine

1



Boring Range 55-300mm
2



Size of Boring Bar 50x1600mm&50x400mm&50x300mm
3



Boring Spindle Speed 50-300RPM
4

Boring Capacity

The Maximum Boring Depth 8mm on One Side
5



Surface Roughness Ra3.2
6



Hole Roundness Error ≤0.02mm
7



Welding Range 40-300mm
8

Welding Capacity

Welding Rod Length 800mm&300mm&240mm&200mm
9



Welding Thickness One Side 4-5mm

10



Welding Wire Diameter 0.8/1.0/1.2mm

11

Max Axial Travel 300mm (Can be customized, Maximum 1000mm)

12

Axial Feeding Speed 0-0.8m/min

13

Motor Power 3.1kw

14

Voltage & Frequency 220V, 60hz/380V, 50Hz
