1" Metric Deep Hexagon (Thinwall)


impact Metric Deep Hexagon (Thinwall)
A/F
mm
MODEL
NO.
D1
mm
D2
mm
T
mm
C
mm
OAL
mm
Wt.
Kg.
22
23
24
S-16M 22LT
S-16M 23LT
S-16M 24LT
35.6
37.0
38.3
54.0
54.0
54.0
14.0
14.0
16.0
80.0
80.0
80.0
110.0
110.0
110.0
1.05
1.05
1.05
25
26
27
S-16M 25LT
S-16M 26LT
S-16M 27LT
39.5
40.8
42.0
54.0
54.0
54.0
16.0
16.0
16.0
80.0
80.0
80.0
110.0
110.0
110.0
1.10
1.10
1.10
28
29
30
S-16M 28LT
S-16M 29LT
S-16M 30LT
43.3
44.5
45.9
54.0
54.0
54.0
16.0
16.0
21.0
80.0
80.0
80.0
110.0
110.0
110.0
1.15
1.15
1.22
31
32
33
S-16M 31LT
S-16M 32LT
S-16M 33LT
47.0
48.3
49.5
54.0
54.0
54.0
21.0
21.0
21.0
80.0
80.0
80.0
110.0
110.0
110.0
1.21
1.25
1.27
34
35
36
S-16M 34LT
S-16M 35LT
S-16M 36LT
50.8
52.0
53.4
54.0
54.0
54.0
21.0
21.0
25.0
80.0
80.0
80.0
110.0
110.0
110.0
1.30
1.30
1.30
37
38
39
S-16M 37LT
S-16M 38LT
S-16M 39LT
54.0
55.9
57.1
54.0
54.0
54.0
25.0
25.0
25.0
80.0
80.0
80.0
110.0
110.0
110.0
1.45
1.50
1.60
40
41
42
S-16M 40LT
S-16M 41LT
S-16M 42LT
58.1
59.9
60.9
54.0
54.0
54.0
25.0
28.0
28.0
80.0
80.0
80.0
110.0
110.0
110.0
1.60
1.60
1.65
43
44
S-16M 43LT
S-16M 44LT
61.9
63.4
54.0
54.0
28.0
28.0
80.0
80.0
110.0
110.0
1.70
1.70
45
46
S-16M 45LT
S-16M 46LT
64.6
65.9
54.0
54.0
28.0
28.0
80.0
80.0
110.0
110.0
1.70
2.15
